Description
The Haematology 3-Part Analyser is a fully automated laboratory instrument used for complete blood count (CBC) testing. It performs 3-part differentiation of white blood cells (lymphocytes, monocytes, and granulocytes) and provides multiple haematological parameters such as WBC, RBC, HGB, HCT, MCV, MCH, MCHC, and platelet counts. The analyser uses electrical impedance and colorimetric methods to deliver accurate results with a throughput of up to 60 samples per hour, making it suitable for diagnostic laboratories, hospitals, and clinics.
General Specifications
Product Type: Analysers
Intended Use: The 3-Part Haematology Analyser is intended for the in vitro quantitative determination of haematological parameters in human whole blood, including white blood cells (WBC), red blood cells (RBC), haemoglobin (HGB), platelets (PLT), and related indices, and for the 3-part differential classification of WBCs (lymphocytes, monocytes/mid cells, and granulocytes).
Technical Features
Counting System: Dual-channel counting system using impedance technology with a cyanide-free haemoglobin method
Storage Capacity: Up to 500,000 result storage capacity
Output: Provides 21 parametres with 3 histograms for detailed analysis
General Characteristics
Assay Principle: Electrical impedance (Coulter Principle) for cell counting and colorimetric photometry method for haemoglobin determination
Detection System/Principle:
- Electrical impedance method for RBC, WBC, and PLT counting
- Haemoglobin measurement by non-cyanide colorimetric photometric method
- 3-part WBC differential (lymphocytes, monocytes, granulocytes)
Specimen Type: Human whole blood (venous or capillary) anticoagulated with EDTA. Sample Volume: 9 µL
Assay Time: 60 seconds per sample Throughput: 60 samples per hour
