Description

The glucometer is a compact medical device used to measure and monitor blood glucose levels at different times of the day—such as fasting, post-meal, and bedtime. It helps detect abnormal sugar levels, including hyperglycemia and hypoglycemia, enabling timely action. By providing accurate readings, the glucometer supports insulin dosing and medication adjustments, helps maintain glucose within the target range, and empowers both users and healthcare professionals to make real-time treatment decisions while following personalised care plans.

General Specifications

Product Type: Blood Glucose Monitor

Intended Use: Monitoring blood sugar levels, diabetes management, treatment decision support, lifestyle and diet control, clinical and home use

Technical Specifications

System Technology: Based on GDH-F AD technology

Measuring Range: 20–600 mg/dL (1.1–33.3 mmol/L)

Memory Capacity: 500 blood glucose test results, 100 control solution test results

Type: Fresh capillary blood, venous blood

Calibration Sample: Venous blood test time: 5 seconds

Sample Volume: 1 µL

Hematocrit Range (HCT): 10%–70%

Dimensions: 85 mm (L) × 53 mm (W) × 23.6 mm (H). Weight: 53.8 g (without battery)

Description

Dr. Ngtech-H Hemoglobin Meter is an in vitro diagnostic device that is used for quantitative testing of total hemoglobin in the blood. It is versatile among the most precise and affordable hemoglobin meter. Dr. Ngtech-H is an instrument used to determine the hemoglobin content of the blood by absorbance spectroscopy. Dr. Ngtech-H is useful in emergencies due to its accuracy, ease-of-use, accuracy, and fast delivery of results.

General Specifications

Methodology: Reflectance Photometry

Test Time: Less than 15 seconds

Meter Size: 150 mm × 80 mm × 35 mm

Weight: 71 g (without batteries)

Working Humidity: 5 – 95%obin content analysers

Capabilities: USB Data Transfer to PC and Printer

Strips (Working Environment): Working Temperature 2 – 40°C and Humidity 5 – 95%

Strips (Storage Environment): Storage Temperature 2 – 40°C and Humidity 5 – 95%

Strips Shelf Life: 24 Months

Sample: Whole blood (Capillary, Venous, Arterial)

Units of Measure: g/dL, g/L, mmol/L

Technical Specifications

Sensitivity: More than 80%

Specificity: More than 80%

Sample Volume: 10 µL

Bias (Limits of Agreement): 0.5 g/dL (±1gm/dL)

Accuracy: 98%

Reproducibility: CV: < 3%

Measurement Range: 0 – 25.6 g/dL, 0 – 256 g/L, 0 – 15.9 mmol/L
